Increase productivity in high rise spaces with the Genie® GS-4047 slab scissor lift thanks to its ability to be driven at full height and designed for excellent maneuverability in tight spaces and narrow aisles.

Overview

  • Front-wheel drive and zero inside turning radius
  • Compact dimensions for easily passing through standard double doors
  • 3-ft (0.91 m) extension deck maximum platform workspace
  • 25% gradient to get up slopes and loading ramps

*This product has been discontinued.

Specifications

  • Machine Length: 8 ft 2 in | 2.48 m
  • Weight: 7,185 lb | 3,260 kg
  • Machine Width: 3 ft 11 in | 1.19 m
  • Max Working Height: 44 ft 11 in | 13.70 m
  • Capacity: 550 lb | 249 kg

Additional Information

Options

Chassis Options

  • Automotive-style horn
  • Power inverter, 800W,  24V DC,  120V AC, 60 Hz

Certification Options

  • EE Certification

Platform Options

  • Air line to platform:  ? in. inner diameter
