True start-to-finish machine for indoor and outdoor use, the Genie® GS-3369 DC rough terrain slab scissor lift features a patented full-time oscillating axle which automatically adjusts the axle position based on ground conditions. This rough-terrain capability gives the machine the ability to easily drive through dirt, sand and mud between tasks.

Overview

  • Full-drive working height of 39 ft
  • Electric-drive motor for emissions-free performance
  • Purpose-built for indoor and outdoor construction, maintenance and installation applications with firm, level surfaces
  • 1,000-lb (454 kg) lift capacity

Specifications

  • Max Working Height: 38 ft 8 in | 11.75 m
  • Capacity: 1,000 lb | 454 kg
  • Machine Width: 5 ft 9 in | 1.75 m
  • Weight: 7,672 lb | 3,480 kg
  • Machine Length: 10 ft 3 in | 3.12 m

Additional Information

Options

Chassis Options

  • High capacity batteries, 315 Ah (standard on GS-4069)
  • Automatic leveling hydraulic outriggers
  • Power inverter, 800W, 48V DC, 120V AC, 60 Hz

Chassis – Tire Options

  • Rough terrain, non-marking foam-filled tires (petroleum based)
  • High floatation foam-filled non-marking  tires

Platform Options

  • Air line to platform:  ? in. inner diameter
